| SPECIFICATIONS |
| |
| INSULATION RESISTANCE |
|
| Test Voltage (DC V) |
250V / 500V / 1000V |
| Output Ranges on Open Circuit |
+10% |
| Measuring Ranges |
250V : 0-100M Ohm / 500V : 0-200M Ohm / 1000V : 0-400M Ohm |
| Short Circuit terminal Current |
2mA DC |
| Power Consumption |
Max. consumption current approx. 190mA |
| CONTINUITY |
|
| Measuring Ranges |
0-50 Ohm |
| Accuracy |
+/- 5% of scale length |
| Open Circuit Terminal Voltage |
Appox. 445mV DC |
| Short Circuit Terminal Current |
Appox. 145mV DC |
| Power Consumption |
Max. consumption current approx. 200mA |
| AC VOLTAGE |
|
| AC Voltage Range |
0 ~ 600V AC |
| Accuracy |
+/- 2.5% of scale length |
| Line Frequency Range |
40-1K Hz |
| GENERAL |
|
| Dimension (with housing front cover) |
170(L) x 165(W) x 92(D)mm |
| Weight |
Approx. 970g (battery included) |
| Power Source |
1.5V(SUM-3) x 8 Type AA |
| Accessories |
Fuse (1A, 250V), test leads (TEL-AL11-5), shoulder belt (BET-1800), instruction manual, batteries |
High quality Tau Band movement.
